Insulator in micaver for high temperatures Height 50 mm - with stainless steel AISI 304L inserts: One side female M12 - other side male M12 passing out 35 mm Conform RoHS

Insulator in micaver for high temperatures Height 50 mm - with stainless steel AISI 304L inserts: One side female M12 - other side male M12 passing out 35 mm Conform RoHS

0.00 € 0.00 €

  • Height
  • Power frequency voltage
  • Bottom insert (hex)
  • Insert material
  • Twist
  • Tensile load
  • Creepage distance
  • Diameter
  • Material
  • Flexural
Add to cart
Add to wishlist
General conditions
Delivery time: 2-3 working days
Contactez-nous

Internal Reference: MV52D SS304L
Variants Default Code: MV52D SS304L

Specifications

Height 50 mm
Power frequency voltage 22 kV
Bottom insert (hex) M12
Insert material Nickel-plated steel
Twist 4,5 daN.m
Tensile load 19000 N (1900 daN)
Creepage distance 63,5 mm
Diameter 50 mm
Material Mica
Flexural 4000 N (400 daN)
